Different manufacturers often use the same names for finishes that can vary from company to company. We have a listing that matches finishes from other companies so you can find the right one to blend with your current decor. As some manufacturers use different plating facilities, an exact match can be difficult to find and there is no guarantee of consistency even from the same company. However, because Mountain Plumbing Products uses only one exclusive plating facility for their finishes, our finishes will not vary.
Schedule 20 1-1/2" Tubular ABS Cable Operated Bath Waste & Overflow with Patented Flexible Overflow Neck for 26" to 33" Tub Depths
BDR20S61-2
Complete cable operated bath waste & overflow kit includes pipe with trim kit. Molded in ABS and polypropylene using brass components. Includes a solid brass or plastic molded trim kit. Available in multiple finishes to match every fixture in your bathroom!
- Schedule 20 1-1/2″ Drain
- Patented Flexible Overflow Neck
- For Acrylic, Fiberglass, Cast Iron, Steel, and Whirlpool Tubs
- Can be cut to size by installer
- Vertical Pipe 26″ to 33″
- Horizontal Pipe 22″ to 29″
- Cable Length 50″
Kit Components:
- BDR20S61-2
- TRIMM3
— Product is listed by IAPMO R&T and is in compliance with the following codes:
- Uniform Plumbing Code (UPC®)
- National Plumbing Code of Canada
Standard Finishes
- BRN – Brushed Nickel
- CHBRZ – Champagne Bronze
- CPB – Polished Chrome
- MB – Matte Black
- ORB – Oil Rubbed Bronze
- PN – Polished Nickel
- ULB – Unlacquered Brass
- VB – Venetian Bronze
Group 1 Finishes
- AB – Antique Brass
- ACP – Antique Copper
- PCP – Polished Copper
- PEW – Pewter
- SB – Satin Brass
- SC – Satin Chrome
- WCP – Weathered Copper
Group 2 Finishes
- BN – Black Nickel
- EB – English Bronze
- FG – French Gold
- GPB – Polished Gold
- PVD – Polished Brass
- PVDBB – PVD Brushed Bronze
- PVDORB – PVD Oil Rubbed Bronze
- SG – Satin Gold
- TB – Tuscan Brass
Plastic Molded Finishes
- BL – Black
- BNE – Bone
- BT – Biscuit
- CPP – Polished Chrome
- IW – Ice White
- PW – Polar White
- WH – White
